Description

Product Description

Our in-ground full rise scissor lift has been a very popular design with garages over many years. Garages and tyre shops like the fact that it is in-ground and a space saver giving unobstructed access to your work place. The speed of loading makes it ideal for many types of repairs, but in particular for brakes, cv joints, steering repairs and servicing.

Features

• Low voltage control cabinet for safety
• Remote pendant control operation
• Four cylinder design with anti-surge valves
• Pull out extensions lock
• Height limit switch
• Secondary descending alarm and stop.
• Easy access grease nipples
• CE Approved

Specification

Model: E4G SXB35
Lifting Capacity: 3500kg
A: Lifting Height: 2006mm
B: Minimum Height Level with Floor: (360mm below ground)
C: Platform Length: 1560 to 1780mm
D: Overall Width: 1820mm
E: Width between platforms: 800mm
Motor: 1ph or 3ph
Oil Tank
Gross Weight
