AMGO E4G S400F In-Ground Scissor Lift
The E4G S400F is a newly designed in-ground scissor lift with a 4000kg lifting capacity, perfect for handling heavier and longer vehicles. Its in-ground design provides unobstructed access and maximises workspace efficiency, making it ideal for commercial garages and workshops.
Key Features:
- Lifting Capacity: 4000kg
- Hydraulic System: Supported by 2 x 2 hydraulic cylinders for equalisation
- Safety Features: Automatic mechanical safety device with pneumatic release and photocell configuration for enhanced protection
- Adjustable Platform Length: Ranges from 1654mm to 2054mm to accommodate various vehicle sizes
- Unobstructed Access: Between ramps for easy access underneath the vehicle
- Air Supply Required: To operate pneumatic safety release
- CE Certified
Specifications:
- Model: E4G S400F
- Lifting Capacity: 4000kg
- Lifting Time: 49 seconds
- Max Lifting Height: 2230mm
- Min Height: 350mm
- Runway Length: 1654-2054mm
- Overall Width: 1900mm
- Width Between Platforms: 800mm
- Gross Weight: 917kg
- Motor: 1-phase (12.8 amps) or 3-phase (5.5 amps)
The E4G S400F offers exceptional performance and space-saving benefits for workshops, ensuring safe and convenient access to heavier vehicles.
